Construction

Building construction has become a very normal activity in today’s world. Although the demand for houses is in the upswing, the competition is in the house building business is also alarmingly increasing. Only companies which can offer quality construction are able to stand in the field firmly.

As for Avm Builders, quality is a password in all its constructions. Next comes the finishing of the constructions. These two aspects are possible only because of the two factors which the company employees in all its construction projects. One is using of high quality materials, and the other is knowledgeable work force.

Quality materials and best work force always give incredible result in all projects undertaken by the company.

The company is engaged in the following activities in order to give perfection to the buildings it constructs:

CONSTRUCTION

RENOVATION

CONSULTING

PROMOTING

INTERIORS

icon
SPECIFICATION OF CONSTRUCTION

GROUND + FIRST FLOOR – RS.2200 PER SQ.FT.

STRUCTURE: (Materials Can Be Selected By Client)
  • 2D Working Plan, 3D Elevation Design & Structural Including
  • Cement: Ramco or Ultratech
  • M Sand: Brickwork CM: 1: 6 & All Masonry work
  • RIVER Sand: Plastering Works CM 1:5
  • Roof Height 10'6"
  • Basement Height: Up to 3’0’’ Feet
  • Concrete Grade: RMC or Manual Mix M20 (1: 2 : 4)
  • Steel: ARS or I STEEL XLS Equivalent TMT Rod
  • Chamber Bricks: 9’’ – Inch Thick Exterior Wall / 4.5’’ Inch Interior Walls
  • Parapet Wall: 3’6’’ Feet Height /4.5’’ Inch Height
BASEMENT
  • Using of Earth Ramming machine for High quality compaction result in Basement
ANTI TERMITE TREATMENT
  • Pre-construction anti termite treatment shall be done for the entire Basement building. All doors and window frames will also be treated
PLASTERING
  • Fosroc or Doctor Fixit: Waterproofing oil for internal & external plastering
  • Improve the plaster durability and resistance to water damages
  • Fiber Mesh: R.C.C structural joint area / Concealed Electrical pipe
BATHROOM & PLUMBING
  • Plumbing Pipes: Inner Ashirvad CPVC, Outer PVC Finolex Pipe 6 Kg
  • Fittings: Parry ware/Jaquar Toilet EWC Rs.5000.00/ Basin / 2 in 1 Wall Mixer Rs.5000.00 / Shower Set / Health Faucet / Pillar Tap
WATER PROOFING IN BATHROOMS
  • Bathroom Sunken: Fosroc or Doctor Fixit / 2 Coat of Brush bond
FLOORING: (Design & Model Can Be Selected By Client)
  • All rooms: Somany, Kajaria or Equivalent 4’0’’x2’0’’. Up to Rs.70.0/sq.ft.
  • Balcony & Bath: Antiskid Tile Size 2’0’’ x 2’0’’ Up to Rs.50.00/Sq.ft.
  • Bath Wall Tiles: FULL Height. Size 4’0’’ x 2’0’’ – Up to Rs.50.00/Sq.ft.
  • Car Parking: Heavy Duty Tile Up to Rs.50.0/Sq.ft
STAIRCASE
  • Granite: Tread and Raiser Up to Rs.70.00/sq.ft. / SS 304 Grade Handrail
Kitchen & Dining (Design & Model Can Be Selected By Client)
  • Wall Tile: 2’0’’ Height - 4’0’’ x 2’0’’ Up to Rs.50.0/Sq.ft.
  • Sink: Stainless Steel or Quartz Up to Rs.4000.00
  • Kitchen Granite Top : 10’0’’ Length 2’0’’ Width Up to Rs.150.00/sq.ft.
  • Sink Faucet: Parry ware up to Rs.2000.00
DOORS AND WINDOWS: (Design & Model Can Be Selected By Client)
  • Main Door: Ghana Teak Door Rs.20, 000.00 & Teak Frame / 35mm Thick Door / 5’’x4’’ Frame / Frame Size – 3’6’’x7’0’’.(Frame & Door – Rs.50,000.00)
  • Lock: Main Door Rs.3000.00 /HandleRs.800.0 / Bedroom : Rs.1000.00
  • Room Doors: Flush Door Rs.3500 / Ghana Teak Frame 4’’x3’’ / Size 3’0’’x7’0’’
  • Bathroom Door: WPC Door & Frame / 7’0’’x2’6’’
  • Windows: UPVC Sliding White Window/ 5 mm Pinhead Glass
  • Window Grill: 12 mm Square Rod
PAINTING: ROLLER FINISH (Design & Model Can Be Selected By Client)
  • Inner Wall Putty: 2 Coats of Wall putty / Birla or Equivalent
  • Wall Painting: 1 Coat Of Primer / 2 Coat Of Tractor Emulsion / Asian
  • Exterior Painting: 1 coat of Damp proof Primer / 2 Coat Of ACE / Asian
  • Main Door: Melamine Polish
ELECTRICAL: (Design & Model Can Be Selected By Client)
  • Pipe: Orbit, Anchor or Equivalent PVC tubes of ISI certified
  • Wires: Polycab, Orbit, Kundan or Equivalent cable FRLS
  • Switches: Anchor Roma Modular
  • Distribution: Orbit, Standard & Indo Asian / MCB / DB
  • Hall: Fan -2 no, Light-3 no, 5Amps-5 no, TV -1 no,Network-1 no
  • Kitchen: Fan -1no, Light-2 no, 5amps-4 no, 15amps-2 no, chimney :1 & Exhaust-1no, RO-1no
  • Bedroom- Fan: 1 no, Light-2 no, 5Amps-3 no, AC-1 no
  • Bath: Light-1no, Mirror light-1 no, Exhaust 5amps-1no, Geyser-15 amps
  • Balcony: Light-1no, Washing machine point-15amps-1no
  • Outside: light-2 no’s, Terrace light-2 no’s with calling bell point
Works Included In the Above Specifications (Contractors Scope)
  • Working 2D Plan, Structural, 3D Elevation Design
  • Parapet Walls
  • Main Door Safety Gate
  • Plumbing Line Champers with Manhole covers
  • Terrace & parking Waterline Tab, Rain Water pipelines
  • Common area Light points.(Staircase, Terrace & Gate light)
AMENITIES PROVIDED EXTRA
  • Compound Wall – Rs.2300.0/R.ft or Rs.350.00/Sq.ft.
  • Brick wall Septic tank – Rs.20.00/Ltr
  • R.C.C Sump & Overhead Tank : Rs.25.00/Ltr
  • Terrace Waterproofing & Weathering Tiles Laying : Rs.130.0/Sq.ft.
  • Temporary EB,Electricity Main Connection
  • Building Plan Approval
  • Bore well With Motor line
  • Ramp, Gate & Setback Flooring
  • Civil work Elevation & Special Materials
